Fabric properties
Blackout
Polyester acrylic-coated
340 g/m²
0.44 mm
295 cm
12.7 cm, 300 cm
Features / Technical properties
5-6
Flame retardant
Digital printing
Oeko-Tex
Special colours from 1’000 m
Washing instructions
Optical and solar coefficients (± 5%, DIN EN 410)
| Colour |
|
|
|
|
|
|
|
|---|---|---|---|---|---|---|---|
| Colour 1 | Tv(%) 0.0 | Ts(%) 0.0 | Rs(%) 72.0 | As(%) 28.0 | Tuv(%) 0.00 | Fc() 0.46 | gtot() 0.33 |
| Colour 2 | Tv(%) 0.0 | Ts(%) 0.0 | Rs(%) 70.0 | As(%) 30.0 | Tuv(%) 0.00 | Fc() 0.47 | gtot() 0.34 |
| Colour 3 | Tv(%) 0.0 | Ts(%) 0.0 | Rs(%) 49.0 | As(%) 51.0 | Tuv(%) 0.00 | Fc() 0.61 | gtot() 0.44 |
| Colour 4 | Tv(%) 0.0 | Ts(%) 0.0 | Rs(%) 44.0 | As(%) 56.0 | Tuv(%) 0.00 | Fc() 0.64 | gtot() 0.46 |
| Colour 5 | Tv(%) 0.0 | Ts(%) 0.0 | Rs(%) 17.0 | As(%) 83.0 | Tuv(%) 0.00 | Fc() 0.81 | gtot() 0.58 |
| Colour 6 | Tv(%) 0.0 | Ts(%) 0.0 | Rs(%) 5.0 | As(%) 95.0 | Tuv(%) 0.00 | Fc() 0.89 | gtot() 0.64 |
Fc + gtot: Value calculated with glass: 0.72 / Ug = 1.6 W/m² K, DIN EN 13363-1
Classification of solar shading devices (DIN EN 14501:2021)
| Colour | Glare control | Privacy at night | Sight contact with the outside | Daylight utilisation |
|---|---|---|---|---|
| Colour 1 | Glare control 4 | Privacy at night 4 | Sight contact with the outside 0 | Daylight utilisation 0 |
| Colour 2 | Glare control 4 | Privacy at night 4 | Sight contact with the outside 0 | Daylight utilisation 0 |
| Colour 3 | Glare control 4 | Privacy at night 4 | Sight contact with the outside 0 | Daylight utilisation 0 |
| Colour 4 | Glare control 4 | Privacy at night 4 | Sight contact with the outside 0 | Daylight utilisation 0 |
| Colour 5 | Glare control 4 | Privacy at night 4 | Sight contact with the outside 0 | Daylight utilisation 0 |
| Colour 6 | Glare control 4 | Privacy at night 4 | Sight contact with the outside 0 | Daylight utilisation 0 |
0: No effect, 1: Low effect, 2: Medium effect, 3: High effect, 4: Very high effect
Downloads
On request:
B-s2,d0 (EN 13501-1)
Type B (BS 5867-2)
