Somnia

Applications

Fabric properties

Blackout
Polyester acrylic-coated
445 g/m²
0.70 mm
275 cm
280 cm

Features / Technical properties

4-5
Flame retardant
Fabric must be turned
Oeko-Tex
Special colours from 1’000 m

Washing instructions

-1.5%
-0.75%
Iron only on the face (front) side!
Oeko-Tex IMO

Optical and solar coefficients (± 5%, DIN EN 410)

Colour
Colour 1 Rs(%) 66.2 As(%) 33.8 Fc() 0.50 gtot() 0.36
Colour 2 Rs(%) 66.2 As(%) 33.8 Fc() 0.50 gtot() 0.36
Colour 3 Rs(%) 66.2 As(%) 33.8 Fc() 0.50 gtot() 0.36
Colour 4 Rs(%) 66.2 As(%) 33.8 Fc() 0.50 gtot() 0.36
Colour 10 Rs(%) 70.4 As(%) 29.6 Fc() 0.47 gtot() 0.34
Colour 12 Rs(%) 70.4 As(%) 29.6 Fc() 0.47 gtot() 0.34
Colour 13 Rs(%) 70.4 As(%) 29.6 Fc() 0.47 gtot() 0.34
Colour 15 Rs(%) 70.4 As(%) 29.6 Fc() 0.47 gtot() 0.34
Colour 16 Rs(%) 70.4 As(%) 29.6 Fc() 0.47 gtot() 0.34
Colour 18 Rs(%) 62.6 As(%) 37.4 Fc() 0.52 gtot() 0.37
Colour 20 Rs(%) 62.6 As(%) 37.4 Fc() 0.52 gtot() 0.37
Colour 21 Rs(%) 62.6 As(%) 37.4 Fc() 0.52 gtot() 0.37
Colour 22 Rs(%) 70.4 As(%) 29.6 Fc() 0.47 gtot() 0.34
Colour 23 Rs(%) 66.2 As(%) 33.8 Fc() 0.50 gtot() 0.36
Colour 24 Rs(%) 62.6 As(%) 37.4 Fc() 0.52 gtot() 0.37
Fc + gtot: Value calculated with glass: 0.72 / Ug = 1.6 W/m² K, DIN EN 13363-1

Downloads

Flame retardant
On request:
Class 1 (UNI 8456)
NFPA 701
IMO
Certificates
